The 2600R005BN3HC Hydraulic Filter is a high-quality replacement filter element designed for demanding hydraulic filtration applications. It is suitable for buyers looking for an alternative to hydraulic filter products used in industrial machinery, hydraulic power units, mobile equipment and other fluid power systems.
This filter is supplied as a Hydac replacement and can be sourced by part number, application or physical dimensions. With a large filter size and robust cartridge construction, it is designed to support reliable contamination control in hydraulic circuits where clean hydraulic fluid is important for protecting pumps, valves, cylinders and other precision components.
Our standard part number is 2600R005BN3HC, with an MOQ of 60 pieces. We also support Hydraulic Filter OEM ODM projects for distributors, filter shops, wholesalers and aftermarket service companies.
The filter uses the part number 2600R005BN3HC and is supplied as a Hydac replacement. Its large cylindrical structure provides a substantial filtration surface, while the specified 145.2 mm outside diameter, 96 mm inside diameter and 919 mm overall length make it suitable for applications requiring a long hydraulic filter element.
A properly matched replacement filter helps maintain hydraulic fluid cleanliness and can reduce the risk of contamination-related wear. Multiple cross-reference numbers also make sourcing easier for professional buyers who manage several brands or aftermarket product lines.
For wholesalers and filter distributors, this product provides a practical way to expand their hydraulic filter range without maintaining separate supply channels for every original brand. Buyers can use the part number or dimensions to identify a suitable replacement before ordering.
Public manufacturer and filtration references identify the 2600 series as hydraulic return-line filter elements. HYDAC's catalog identifies the 2600 R 005 configuration as a hydraulic filter element and lists microglass media, outside-in flow and a 5 μm rating for the 2600 R 005 ON configuration. Related replacement references also list 2600R005BN3HC and 2600R005BN4HC within the same cross-reference family.
| Item | Specification |
|---|---|
| Part Number | 2600R005BN3HC |
| Reference Part Number | 1263064 / 2600R005BNHC |
| Part Type | Hydraulic Filter |
| Brand Reference | Hydac Replacement |
| Outer Diameter | 5.72 inch (145.2 mm) |
| Inner Diameter | 3.78 inch (96 mm) |
| Length | 36.18 inch (919 mm) |
| Gasket ID | 3.73 inch (94.8 mm) |
| MOQ | 60 pcs |
Note: Dimensions above are based on the supplied product specification. Please confirm the exact filter configuration, installation dimensions and part number before bulk ordering. HYDAC's official catalog lists certain 2600 R 005 configurations with different overall dimensions, so configuration-specific verification is recommended.
For purchasing departments, a reliable Hydac Hydraulic Filter Cross Reference can simplify replacement sourcing. The following part numbers are provided as reference numbers for product identification. Always verify dimensions, filter media, seal type, bypass configuration and application before placing an order.
| Brand | Cross Reference Part Numbers |
|---|---|
| Argo | V3149353 |
| Baldwin | PT23104-MPG |
| Donaldson | P567002 |
| Fleetguard | ST1276 |
| Hifi | SH 74132 |
| Hydac | 2600R005BN3HC 2600R005BN4HC |
| Pall | HC2295FCN36H HC2295FKN36H HC2296FCN36H50 HC2296FKN36H50 |
| Parker | 934571 |
| SF Schupp | HY13412 |
| Wix | R44D05GV |
When the original part number is unavailable, Hydraulic Filter By Size is another useful way to identify a replacement. Buyers should compare the outside diameter, inside diameter, overall length, gasket dimensions and end-cap configuration. For this model, the supplied dimensions are 145.2 mm OD, 96 mm ID and 919 mm length, with a 94.8 mm gasket ID.
Size matching should not be based on dimensions alone. Hydraulic filter performance also depends on filtration media, micron rating, flow direction, bypass arrangement, pressure resistance and seal material. Our technical team can check these details against your existing filter or technical drawing before production.
This replacement element can be considered for hydraulic filtration programs where a large cartridge filter is required. Typical B2B applications include:
CHINA EVERLASTING PARTS CO., LIMITED provides Hydraulic Filter OEM ODM services for professional buyers. If you are developing your own filter brand or need an alternative supplier, we can work from an existing part number, physical sample, drawing or technical specification.
OEM and ODM support can help distributors create private-label hydraulic filtration products, while bulk purchasing allows customers to build a stable aftermarket supply program. Our team can also assist with filter identification and cross-reference verification before production.
“The part-number matching process was straightforward, and the supplier provided useful information before our bulk order. This helped us source a replacement filter for our aftermarket customers.”
— Ethan Caldwell, Industrial Filter DistributorExample testimonial for page template
“We needed a reliable alternative for a large hydraulic filter program. The cross-reference list and size information made it easier for our purchasing team to confirm the correct product.”
— Marcus Whitaker, Hydraulic Service CompanyExample testimonial for page template
“The OEM and ODM option is valuable for our filter business. We can discuss part numbers, dimensions and packaging requirements with one supplier for our private-label program.”
— Nathaniel Brooks, Filter Wholesale BuyerExample testimonial for page template
CHINA EVERLASTING PARTS CO., LIMITED is a professional high-quality filters manufacturer serving global B2B customers. Our product range includes Air Filters, Air Cleaner Filters, Air Dryers, Ventilation Filters, Breather Filters, Oil Filters, Fuel Filters, Hydraulic Filters, Fuel Water Separators, Air Oil Separators and Filter Assemblies.
We focus on providing reliable aftermarket filtration products for retailers, after-sales service providers, wholesalers and filter shops. In addition to standard replacement products, we welcome OEM and ODM projects for customers who require customized filtration solutions, private-label products or long-term supply cooperation.
